    EN10147 ASTM Galvanized Steel Coil Coated Iron Sheet Rolled Z30 Zinc

    Ask Lasest Price
    Brand Name : OEM/ODM
    Model Number : Q195
    Certification : ISO
    Price : negotiable based on the quantity
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 1000 tons per month
    Delivery Time : within 10 days after received the advance
    • Product Details
    • Company Profile

    EN10147 ASTM Galvanized Steel Coil Coated Iron Sheet Rolled Z30 Zinc

    Hot Dip Glvanized Steel Coils

    Technical Standard

    EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653


    Steel Grade

    Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490, SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement

    Type

    Coil/Sheet/Plate/Strip

    Thickness

    0.12-6.00mm, or customer's requirement

    Width

    600mm-1500mm, according to customer's requirement

    Type of Coating

    Hot Dipped Galvanized Steel(HDGI)

    Zinc Coating

    30-275g/m2

    Surface Treatment

    Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)

    Surface Structure

    Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)

    Quality

    Approved by SGS, ISO

    Coil Weight

    3-20 metric ton per coil

    Package

    Water-proof paper is inner packing, galvanized steel or coated steel sheet is outer packing, side guard plate, then wrapped by seven steel belt. or according to customer's requirement

    Export market

    Europe, Africa, Central Asia, Southeast Asia, Middle East, South America, North America, etc

    Thickness

    0.13-3.0mm

    Width

    Galvanized steel strip:24-600 mm; galvanized steel coil:600-1250mm

    Coil weight

    Usually is 3-4.5 tons,the max coil is 10 tons

    Zn coating

    0.13-0.8 mm is 30-150 g/m2; 0.8-1.5 mm is 30-180 g/m2;1.5-6.0 mm is 30-275 g/m2

    Coil ID

    600-1500 mm,Normal width is 91 4/1000/1219/1250/1500 mm

    Steel grade

    DX51D,DX52D,DC01,DC02,SGHC

    Surface

    regular/mini/big/zero spangle,skin pass, chromated, unoiled, dry

    Packaging

    seaworthy export standard package, or according to the customers’requirement

    Delivery time

    With 15 –25 days after receipt of deposit or L/C

    Market

    North/South America, Europe, Asia,Africa,Mid East

    Productivity

    2000 Metric ton /month

    EN10147 ASTM Galvanized Steel Coil Coated Iron Sheet Rolled Z30 ZincEN10147 ASTM Galvanized Steel Coil Coated Iron Sheet Rolled Z30 ZincEN10147 ASTM Galvanized Steel Coil Coated Iron Sheet Rolled Z30 ZincEN10147 ASTM Galvanized Steel Coil Coated Iron Sheet Rolled Z30 Zinc
    Product Advantages
    01. Anticorrosive:13 years in heavy industrial areas,50 years in the ocean,104 years in the suburbs and 30 years in cities.
    02. Cheap:The cost of hot-dip galvanizing is lower than that of other coatings.
    03. Reliable:The zinc coating is metallurgically bonded to the steel and forms part of the steel surface,so the coating is more durable.
    04. Strong toughness:The galvanized layer forms a special metallurgical structure that can withstand mechanical damage during transportation and use.
    05. Comprehensive protection:Every part of the plated piece can be galvanized,and is fully protected even in depressions,sharp corners,and hidden places.
    06. Save time and energy:Galvanizing process is faster than other coating methods.
    If you have any question, please feel free to contact us any time.
