BA 8k 2205 S32750 Super Duplex Steel Plate Decorative Steel Plate
2507 is the most common “super” duplex grade.
Usage of Duplex 2507 should be limited to applications below 6000 F
(3160 C). Extended elevated temperature exposure can reduce both
the toughness and corrosion resistance of alloy 2507.The high
chromium, molybdenum, and nitrogen levels provide excellent
resistance to pitting, crevice, and general corrosion.the duplex
structure provides 2507 with exceptional resistance to chloride
stress corrosion cracking.
Duplex 2507 possesses excellent mechanical properties. Often a
light gauge of 2507 material can be used to achieve the same design
strength of a thicker nickel alloy. The resulting saving in weight
can reduce the overall cost of fabrication.
Super Duplex Corrosion Resistance, The high chromium and molybdenum
content of Super Duplex makes it extremely resistant to uniform
corrosion by organic acids like formic and acetic acid. Super
Duplex also provides excellent resistance to inorganic acids,
especially those containing chlorides.
• High resistance to chloride stress corrosion cracking
• High Strength
• Superior resistance to chloride pitting and crevice corrosion
• Good general corrosion resistance
• Suggested for applications up to 6000 F
• Low rate of thermal expansion
• Combination of properties given by austenitic and ferritic
structure
• Good weldability and workability
Duplex plates/sheets |
Standard details: |
Duplex UNS S31803/UNS S32205, Duplex F51, Duplex SA182 Grade F-51,
DIN 1.4462 |
Duplex A182-F51, Duplex SA182 Grade F-51 UNS S31803, UNS S32205,
Din-1.4462 |
Duplex ASTM A182 Grade F60 / ASME SA182 Grade F60 NACE & Norsok
Approved |
Super Duplex 2507, Super Duplex SAF2507 Super Duplex SAF 2507 ASTM
A182 Grade F53 |
Super Duplex F53, Super Duplex SA182 Grade F-53, Super Duplex
S32750 |
Super Duplex UNS S32760 F55 ASTM A182 F-55 SA182 F55 DIN 1.4501 UNS
32760 |
ASTM / ASME SB 163 UNS 2200 ( NICKEL 200 ) |
ASTM / ASME SB 163 UNS 2201 (NICKEL 201 ) |
ASTM / ASME SB 163 / 165 UNS 4400 (MONEL 400 ) |
ASTM / ASME SB 464 UNS 8020 ( ALLOY 20 / 20 CB 3 ) |
ASTM / ASME SB 704/705 UNS 8825 INCONEL (825) |
ASTM / ASME SB 167 / 517 UNS 6600 (INCONEL 600 ) |
ASTM / ASME SB 167 UNS 6601 ( INCONEL 601 ) |
ASTM / ASME SB 704 /705 UNS 6625 (INCONEL 625) |
ASTM / ASME SB 619/622/626 UNS 10276 ( HASTELLOY C 276 ) |
Copper Alloy |
ASTM / ASME SB 111 UNS NO. C 10100, 10200, 10300, 10800, 12000,
12200, 70600, 71500. |
ASTM / ASME SB 466 UNS NO. C 70600 ( CU -NI- 90/10), C 71500 ( CU
-NI- 70/30) |
Characteristics and application |
2B | The surface brightness and flatness of 2B is better than 2D.then
through a special surface treatment to improve its mechanical properties.2B could nearly
satisfy comprehensive uses. |
NO.3 | Polished with abrasive belt of git#100#200,have better brightness
with discontinuous coarse stria,used as inner and external ornaments for
building,electrical appliances and kitchen utensils etc. |
NO.4 | Polished with abrasive belt of grit#150#180.have better brightness
with discontinuous coarse stria.but thinner than NO.3,are used as bathtub buildings
inner and external ornaments electrical appliances kitchen utensils and food
processing equipment etc. |
HL | Polished with abrasive belt of grit#150#320 on the NO.4 finish and
has continuous streaks, mainly used as buildings ornaments elevators, door of building,
frontal plate etc. |
BA | Cold rolled, bright annealed and skin-passed, the product have
excellent brightness and good reflexivity like mirror, kitchen apparatus, ornament etc. |
8K | The product have excellent brightness and prefer reflexivity can be
the mirror. |
Mechanical properties |
| Heat Treatment | Yield strength(N/mm2) | Tensile strength | Elongation (%) | Hardness |
363 |
2507 | S | ≥550 | ≥965 | ≥30 |
Applications:
Oil and gas industry equipment
Offshore platforms, heat exchangers, process and service water
systems, fire-fighting systems, injection and ballast water systems
Chemical process industries, heat exchangers, vessels, and piping
Desalination plants, high pressure RO-plant and seawater piping
Mechanical and structural components, high strength,
corrosion-resistant parts
Power industry FGD systems, utility and industrial scrubber
systems, absorber towers, ducting, and piping
Specifications:
| Sizes | | Standard Tolerances |
Products | OD | Wall | Lengths and /or coils | Grades | OD | Wall | Lengths |
Pressure & Corrosion Tubing Meets or exceeds requirements forwelded Specification: ASTM-A789 | 1/16" (1.59 mm) to 4" (101.6 mm) Metric sizes available | 0.010" (0.25 mm) to 0.220" (5.59 mm) | Random or cut lengths up to 40' (12.2 m) Coils to 1-1/2" OD | Super Duplex 2507 | <1-1/2" (38.1 mm) ±0.005" (0.13 mm) 1-1/2" (38.1 mm) to 3" (76.2 mm) ±0.010" (0.25 mm) 3-1/2" (88.9 mm) to 4" (101.6 mm) ±0.015" (0.38 mm) | ±10% | Randoms up to +2" (50.8 mm) Cuts +1/8" (3 mm) -0" Coils to 80,000' (24,384 m) |
Subsea Umbilical Tubing Specifications: ASTM-A789 and ASTM-A790 | 3/8" (9.53 mm) to 1-1/2" (38.1 mm) | 0.039" (0.99 mm) to 0.125" (3.18 mm) | Cut lengths to 60' (18.3 m) Coils to 1-1/2" OD* | Super Duplex 2507 | ±0.005" (0.127 mm) | ±10% | Coils to 80,000' |
Duplex Heat Resistance
SAF 2507 should be solution annealed and quenched after either hot
or cold forming. Solution annealing should be done at a minimum of
1925F. Annealing should be followed immediately by a rapid air or
water quench. To obtain maximum corrosion resistance, heat treated
products should be pickled and rinsed.
